Description

Engine Specifications:
– Vanguard. model 3564
– Air cooled engine
– 2-cylinder, 4-stroke gasoline engine
– Electric start with recoil start as backup
– 6 gallon (22 l) detachable fuel tank

Pump Specifications:
– Transmission drive C.E.T Single stage centrifugal pump
– Belt drive transmission
– Pump body made from high resistant aluminum alloy
– Bronze impeller
– Mechanical shaft seal
– Stainless steel pump shaft
– Exhaust priming system, guaranteed up to 20’ (6 meter lift)
– One 1-1/2’’ (38mm) delivery outlet with Fire Type swing-out valve
– One 2-1/2’’ (65 mm) suction inlet
– Dimensions: L 700 x W 559 x H 610 (mm)
– Weight: 74 kg

Performance:
– 115 GPM @ 50 PSI
– 100 GPM @ 100 PSI
– 70 GPM @ 150 PSI
– 45 GPM @ 200 PSI
– 20 GPM @ 250 PSI
