Description

Engine Specifications:
– CH440 Kohler air cooled engine
– Single cylinder, 4-stroke gasoline engine
– 12V electric start with recoil start as backup
– 1.8 gallon (7 l) integrated fuel tank
– 10 amp. charging system

Pump Specifications:
– C.E.T. Single stage centrifugal pump, direct drive
– Pump body made from high resistance aluminum alloy
– Bronze impeller
– Mechanical shaft seal
– Exhaust priming system, guaranteed up to 24’ (7.5 meter) lift
– One 1 1/2” (38 mm) delivery outlet with 1/4-turn ball valve
– One 2 1/2” (64 mm) suction inlet
– Dimensions: L 552 x W 673 x H 514 (mm)
Wet weight: 74 kg

Performance:
– MAX FLOW : 240 GPM
– MAX PRESSURE: 170 PSI
– 205 GPM @ 25 PSI
– 175 GPM @ 50 PSI
– 115 GPM @ 100 PSI
