Description

Engine Specifications:
– Vanguard, model 380000
– Air cooled engine
– V-Twin cylinder, 4-stroke gasoline engine
– 12V electric start with recoil start as backup
– 6 gallon (22 l) detachable fuel tank

Pump Specifications:
– Transmission drive C.E.T. single stage centrifugal pump
– Pump body made from resistant aluminum alloy
– Bronze impeller
– Mechanical shaft seal
– Stainless steel pump shaft
– Belt drive transmission
– Exhaust priming system, guaranteed up to 20’ (6 mtr) lift
– One 1-1/2” delivery outlet with Fire Type swing-out valve
– One 2 1⁄2” (65 mm) suction inlet
– Dimensions: L 700 mm x W 560 x H 610 (mm)
– W eight: 75 kg

Performance:
– 140 GPM @ 50 PSI
– 125 GPM @ 100 PSI
– 90 GPM @ 150 PSI
– 60 GPM @ 200 PSI
– 25 GPM @ 275 PSI
