Description

Engine Specifications:
– GX630 Honda air cooled engine
– V-Twin cylinder, 4-stroke gasoline engine
– Electric start
– 6 gallon (22 l) detachable fuel tank

Pump Specififications:
– C.E.T. single stage centrifugal pump
– Pump body made from high resistance aluminum alloy
– Bronze impeller
– Mechanical shaft seal
– Exhaust priming system, guaranteed up to 6 mtr lift
– Two 2 1⁄2” (65 mm) delivery outlet with 1/4-turn ball valve
– One 4” (100 mm) suction inlet
– Dimensions: L540 x W 673 x 610 mm
– Weight: 90 kg

Performance:
– MAX FLOW : 630 GPM
– MAX PRESSURE : 105 PSI
– 410 GPM @ 25 PSI
– 300 GPM @ 50 PSI
– 100 GPM @ 100 PSI
