Description

Engine Specifications:
– Vanguard, model 380000, air cooled engine
– V-Twin cylinder, 4-stroke gasoline engine
– Electric start with recoil start as backup
– 6 gallon (22 l) detachable fuel tank

Pump Specififications:
– C.E.T. single stage centrifugal pump
– Pump body made from high resistance aluminum alloy
– Bronze impeller
– Mechanical shaft seal
– Exhaust priming system, guaranteed up to 20’ (6 meter) lift
– One 2 1/2” (65 mm) delivery outlet with Fire Type swing-out valve
– One 4” (100 mm) suction inlet
– Dimensions: L540 x W 673 x H610 mm
– Weight: 79,5 kg

Performance:
– MAX FLOW : 550 GPM
– MAX PRESSURE : 115 PSI
– 455 GPM @ 25 PSI
– 350 GPM @ 50 PSI
– 160 GPM @ 100 PSI
